Technical Data
Specification
| Conductivity K = 0,475 | ||
| Range | Resolution | Accuracy |
| 0.0 to 475µS/cm | 0.1µS/cm | ±1% of reading +2µS/cm |
| 475 to 4750µS/cm | 1µS/cm | ±1% of reading +5µS/cm |
| 4.75 to 47,50mS/cm | 0,01mS/cm | ±1% of reading +0,05mS/cm |
| 47,5 to 200,0mS/cm | 0,1mS/cm | ±2,5% of reading +0,5mS/cm |
| Conductivity K = 0,1 | ||
| Range | Resolution | Accuracy |
| 0.00 to 99,99µS/cm | 0.01µS/cm | ±1% of reading |
| 100 to 200µS/cm | 0,1µS/cm | ±1% of reading |
| Salinity | ||
| Range | Resolution | Accuracy |
| 0.0 to 70,0 ppt | 0.1 ppt | ±0,2 % Full Scale |
| Temperature | ||
| Range | Resolution | Accuracy |
| -10.0 to 90,0 °C | 0.1 °C | ±0,2 % or ±4% Full Scale whichever is greater |
| Specification | ||
| Reference Temp.: | From 15,0 to 25,0°C, default is 25,0°C | |
| Temperature Coefficient: | From 0.00 to 4,00 °C, default is 1,91°C | |
| TDS Constant: | From 0,30 to 1.00, default is 0,65 | |
| Cell Constant | 4 wire conductivity cell: K = 0,475 | |
| ATC | Thermistor, 10K ohms, at 25°C | |
| Power | 9 Volt battery | |
| Size (LxWxD) (mm) | 196x70x37 | |
| Weight (g) | 0,26 kg (Battery included) |
