Ashing furnaces up to 900 °C

BASIC MODEL
-Solid ceramic chamber
-Enclosed heating elements are in four sides around the chamber
-Fan-assisted chimney for smoke and humidity extraction
-Continuous air change in the chamber
-Door opens sideways
-Door safety interlock switch
-Control panel is placed in the underpart of the furnace
-Microprocessor – temperature controller
-Ceramic bottom plate
-Outside casing – metal sheet, powder painted grey
-High quality, ecological thermal insulation material
-Low electric power consumption
-Short heating up/cooling down period
-High degree of accuracy
-1 year warranty

OPTIONS
-Process observation window (Ø 35 mm) up to 1100 °C
-Additional ceramic hearth plates
-Buzzer
-Digital timer
-Protection against overheating
-Data recorder
-Data communication/USB
-Calibration of temperature measurement system
-Table for supporting the furnace
-Additional 1 year warranty

Clear
SKU: N/A Categories: , , Tag:

Technical Data

SNOL 4/900 LSC21 & SNOL 4/900 LSC21 ST

Useful volume Liter 4
Rated power not more than kW 3,7
Rated supply voltage V 230
Rated frequency Hz 50
Number of phases – 1
Continuous operating temperature °C T+10-900
Maximum  temperature °C 900
Working chamber material – Ceramic
Maximum heating- up time (without charge) Min. 100
Temperature stability in working chamber at rated temperature in thermal steady state without charge not more than ± °C 2
Temperature uniformity in working space at rated temperature in thermal steady state without charge not more than ±°C 10
Furnace working chamber dimensions:
width mm 120
depth mm 295
height mm 110
Furnace external dimensions:
width mm 440
depth mm 605
height mm 500*
Mass kg 41

SNOL 7.2/900 LSC21 & SNOL 7.2/900 LSC21 ST:

Useful volume Liter 7,2
Rated power not more than kW 3,3
Rated supply voltage V 230
Rated frequency Hz 50
Number of phases – 1
Continuous operating temperature °C T+10-900
Maximum  temperature °C 900
Working chamber material – Ceramic
Maximum heating- up time (without charge) Min. 130
Temperature stability in working chamber at rated temperature in thermal steady state without charge not more than ± °C 1
Temperature uniformity in working space at rated temperature in thermal steady state without charge not more than ±°C 10
Furnace working chamber dimensions:
width mm 195
depth mm 295
height mm 120
Furnace external dimensions:
width mm 445
depth mm 640
height mm 525*
Mass kg 51
