Furnaces with ceramic chambers up to 900 °C

High accuracy electric furnace with solid ceramic chamber is intended for hardening, loosening, normalizing and other thermal processing up to 900°C. To eliminate gasses or smokes that are released during thermal processing, exhaust system may be additionally installed in the products. The furnace is excellent fit for scientific laboratories, educational institutions, medicine and industry.

Clear
SKU: N/A Categories: , , Tag:

Technical Data

SNOL 4/900 LSC01 & SNOL 4/900 LSC01 ST:

Technical data Dimension  SNOL 4/900 LSC01
Useful volume Liter 4
Rated power not more than kW 3,7
Rated supply voltage V 230
Rated frequency Hz 50
Number of phases – 1
Continuous operating temperature °C T+10-900
Maximum  temperature °C 900
Working chamber material – Ceramic
Maximum heating- up time (without charge) Min. 100
Temperature stability in working chamber at rated temperature in thermal steady state without charge not more than ± °C 2
Temperature uniformity in working space at rated temperature in thermal steady state without charge not more than ±°C 10
Furnace working chamber dimensions:
width mm 120
depth mm 295
height mm 110
Furnace external dimensions:
width mm 440
depth mm 555
height mm 500
Mass kg 41

SNOL 7.2/900 LSC01 & SNOL 7.2/900 LSC01 ST:

Technical data Dimension  SNOL 7,2/900 LSC01
Useful volume Liter 7,2
Rated power not more than kW 3,3
Rated supply voltage V 230
Rated frequency Hz 50
Number of phases – 1
Continuous operating temperature °C T+10-900
Maximum  temperature °C 900
Working chamber material – Ceramic
Maximum heating- up time (without charge) Min. 130
Temperature stability in working chamber at rated temperature in thermal steady state without charge not more than ± °C 1
Temperature uniformity in working space at rated temperature in thermal steady state without charge not more than ±°C 10
Furnace working chamber dimensions:
width mm 195
depth mm 295
height mm 120
Furnace external dimensions:
width mm 445
depth mm 590
height mm 525
Mass kg 51

SNOL 12/900 LSC01 & SNOL 12/900 LSC01 ST:

Technical data Dimension  SNOL 12/900 LSC01
Useful volume Liter 12
Rated power not more than kW 4
Rated supply voltage V 230
Rated frequency Hz 50
Number of phases – 1
Continuous operating temperature °C T+10-900
Maximum  temperature °C 900
Working chamber material – Ceramic
Maximum heating- up time (without charge) Min. 110
Temperature stability in working chamber at rated temperature in thermal steady state without charge not more than ± °C 1
Temperature uniformity in working space at rated temperature in thermal steady state without charge not more than ±°C 10
Furnace working chamber dimensions:
width mm 215
depth mm 295
height mm 195
Furnace external dimensions:
width mm 640
depth mm 745
height mm 820
Mass kg 134

SNOL 15/900 LSC01 & SNOL 15/900 LSC01 ST:

Technical data Dimension  SNOL 15/900 LSC01
Useful volume Liter 15
Rated power not more than kW 6
Rated supply voltage V 400
Rated frequency Hz 50
Number of phases – 3
Continuous operating temperature °C T+10-900
Maximum  temperature °C 900
Working chamber material – Ceramic
Maximum heating- up time (without charge) Min. 100
Temperature stability in working chamber at rated temperature in thermal steady state without charge not more than ± °C 1
Temperature uniformity in working space at rated temperature in thermal steady state without charge not more than ±°C 10
Furnace working chamber dimensions:
width mm 215
depth mm 400
height mm 195
Furnace external dimensions:
width mm 640
depth mm 815
height mm 820
Mass kg 130
