Technical Data
Specification
Features:
- OptiFill dispenser is standard
- TapWater set for direct connection to a drinking water tap
- 10-litre pure water tank has a pressure outlet
- Tank volume display in percent
- Simple and economical filter replacement
- Leakage sensor is standard
- Type ASTM I dispensing performance is 1,6 / 2 l/min.
- Type ASTM II draw-off is up to 6 l/h / 12 l/h
- Ready-to use, including filter cartridges
(Pre-treatment cartridge with RO membrane and ultrapure water cartridge)
The BOECOpure PLUS UV is supplemented with UV-oxidation, 185/254 nm.
The BOECOpure PLUS UV/UF is supplemented with an ultrafilter and UV-oxidation, 185/254 nm.
ASTM Type I Ultrapure water applicable for Molecular biology, microbiology, PCR, inorganic and organic trace analysis HPLC, ICP, TOC-analysis
ASTM Type II pure water applicable for Rinsing laboratory glassware, preparing and diluting buffers, reagents, tissue culture media and dyes.
Sample preparation for analytical methods such as flame AAS
| Specification ASTM II: | Standard | UV | UV/UF |
| Pure water performance at 15°C: | 6l/h | 6 or 12 l/h | 6 l/h |
| Conductivity: | 0.067-0.1µS/cm | ||
| Resistance: | 15-10 MO x cm | ||
| Pure water tank pressurized outlet | yes | ||
| Specification ASTM I | Standard | UV | UV/UF |
| Conductivity: | 0.055 µS/cm | ||
| Resistance: | 18.2 MO x cm | ||
| Bacterial ** content: | 5-10 ppb | 1-5 ppb | 1-5 ppb |
| Dispensing performance: | up to 2 l/min | up to 2 l/min | up to 1.6 l/min |
| Bacterial ** content: | < 1 CFU/ml | ||
| Particles ** content: | < 1ml | ||
| Endotoxines* | 0.001 EU/ml | ||
| Feedwater requirements | |
| Drinking water acc. to DIN 2000 Feedwater temperature: | + 2°C up to + 35°C |
| Manganese and iron content: | < 0,05 mg/l |
| Free chlorine content: | < 1 mg/l |
| Silt density index (SDI): | max. 3 |
| Technical data | |
| Operating pressure in bar, min./max. | 0,5-6 bar |
| Supply voltage: | 100-240 V / 50-60 Hz |
| Connected load: | 0.1 kW |
| Connector size: | 8 mm hose |
| Ambient temperature: | + 2°C up to + 35°C |
| Dimensions ***, W x D x H: | 390 x 725 x 615 mm |
| Weight: | 20/21 kg |
* in dependence on the feedwater quality
** with sterilizing filter 0,2 µm
*** with OptiFill Dispenser
