Name: Multi-chamber ovens forced air circulation, Tmax: 200 oC, Volume: 240lt x 2, Stainless 304
SKU: SNOL 2x240/200 LSN11

Multi-chamber ovens forced air circulation, Tmax: 200 oC, Volume: 240lt x 2, Stainless 304

Made from high quality materials such as heavy-duty metal parts and thermal insulation materials
Chamber made from mild or stainless steel
The door can opens to the sideways only
Has forced air circulation allows a homogenous temperature distribution to be achieved and ensures optimal results for processes such as drying, perliminary heating and other thermal processes
The temperature range is up to 200 deg C
The ovens have either 2 or 4 shelves
PLEASE CONTACT US FOR THE PRICE

SKU: SNOL 2x240/200 LSN11 Categories: Laboratory Equipment, Oven Tag: Oven

Technical Data

Technical data	Dimension	SNOL 2×240/200 LSN11
Useful volume	Liter	2×240
Rated power not more than	kW	24
Rated supply voltage	V	380
Rated frequency	Hz	50
Number of phases	–	3
Continuous operating temperature	°C	50-200
Maximum temperature	°C	200
Working chamber surroundings	–	air
Airflow		Forced air circulation
Shelves (number)/max.		4
Maximum heating- up time (without charge) up to 200°C	Min.	60
Temperature stability in working chamber at rated temperature in thermal steady state without charge not more than	± °C	2
Oven working chamber dimensions:
width	mm	500
depth	mm	400
height	mm	1200
Outside dimensions:
width	mm	1500
depth	mm	960
height	mm	1715
Mass	kg	450
