UV Online Analyzer for COD BOD TOC TSS NO3 STAC2 1 way

The STAC2 scans and measures the entire absorption spectrum and creates a unique fingerprint from the sample. STAC technology is used by many customers worldwide as a vital decision making tool in their water quality monitoring. The STAC2 is the only analyser in the world that can measure and analyze a multitude of organic substances without using reagents.

The STAC2 analyser is a technologically advanced instrument, able to be connected to an Ethernet or WIFI network. There is no screen on the instrument itself, and the human interface is based on an embedded Web page, which users can access via the network. This Web Page enables the customer to manage the entire configuration, status and results of the STAC2.

SKU: 70MP0610 Categories: , Tag:

Technical Data

Sample streams 4 Different samples
Dimensions Height: 500 mm Width: 400 mm Depth: 265 mm
Weight 18 kg
Protection IP53
Digital output 1x Ethernet RJ45 port for MODBUS and/or HMI access

1x WIFI connection for HMI access

1x USB port for USB Key recorded data history backup
Flow cells Interchangeable 2, 5 and 50mm optical path
Cleaning Automatic, chemical for tubing / Internal case by compressed air
Lamp Xenon
Blank Automatic
Data readout On separate PC / tablet or mobile phone (optional)
Operating temperature 10°C to 40°C / 50°F to 104°F
Data Storage On internal SD Card. An internal security back-up is performed daily on internal USB drive. Data export on internal USB key.
Mounting Wall-mounted
Digital input / output Through MODBUS TCP/IP and RTU
Power 24VDC +/-0.5VDC 3A or 100 – 240V (Optional) 50-60Hz with External Power supply
Measuring range • COD : 2 to 8750 mg/L   • BOD : 0.5 to 8750 mg/L

• TOC : 1 to 7500 mg/L   • TSS : 5 to 2500 mg/L

• NO3 : 1 to 1000 mg/L    • Turbidity compensation
